Solinst SolSat 5 Satellite Telemetry

  • Global connectivity with Iridium satellite technology
  • Cost-effective compared to other satellite telemetry systems
  • Compact and weatherproof housing for deployment in any environment and long-term applications
  • Secure and convenient data transmission and alarm alerts through TextAnywhere
Product Options
9700 Reader Cable - 6 ft
116895

Overview

SolSat 5 Satellite Telemetry is an advanced telemetry system that leverages Iridium satellite technology to provide global connectivity for your remote water monitoring projects. The SolSat 5 is simple to set up with Solinst dataloggers using an integral, secure Wi-Fi App on your smartphone.

SolSat 5 combines intelligent electronics with builtin sensors, alarm capabilities, and storage for up to 100,000 readings, allowing efficient satellite transmissions and power usage while providing high data integrity.

The SolSat 5 is compact, lightweight, and features a robust weatherproof enclosure. SolSat 5 is deployed anywhere with very little site preparation, saving you costs and time in the field. A built-in solar panel extends the battery life, and you can easily add a second panel. SolSat 5 Satellite Telemetry connects to one Solinst datalogger. The built-in barometric sensor allows for automatically compensated water level data reported from the field.

Along with water level, temperature, conductivity,and barometric data, battery voltage from the remote SolSat 5 is received with each data report.

Manufactured by: Solinst
Model: Solinst SolSat 5 Satellite Telemetry

Services offered for this product

  • Sales
  • Rental
  • Installation
  • Calibration
  • Maintenance
  • IoT Cloud Compatible

Specification

Communication: 9603 Iridium SBD Satellite Modem
Communication Distance: Global coverage (*clear view to the sky required for best performance and battery life)
Antenna: High-performance helical (SMA connector)
Data File Type: Sent via SMS, export as .csv or .xle
Sampling Interval: Hourly
Reporting Interval: Daily, every 6 hours, or hourly
Schedule Programming: Wi-Fi App (browser) on your smart device or laptop
Power Supply: 2 x 3.4 Ah LiPo batteries
Battery Charging: USB 5 volts, built-in 2 Watt 325 mAh solar panel, optional additional solar panel
Battery Life Estimate: 2–3 years* (based on hourly samples and one satellite transmission per day)
Memory Capacity: 100,000 readings (wrap-around memory)
Operating Temperature: -20°C to +55°C
Weight: 535 grams (18.9 ounces)
Size: 19.1 cm x 16.4 cm x 6.4 cm (7.5" x 6.5" x 2.5")
IP Rating: IP66
Compatible Dataloggers: Levelogger 5, Barologger 5, Levelogger 5 Junior, Levelogger 5 LTC, LevelVent 5
Connected dataloggers: 1
Barometric Compensation: Internal barometer for automatic barometric compensation of water level data if a Barologger is not being used (not required for vented loggers)
Internal Barometer Range: 30 kPa – 110 kPa
Internal Barometer Accuracy: ±0.1 kPa (1 cm)
Warranty: 1 Year

Downloads

Accessories

Related products

FAQ's

No, Solinst certifies that PFAS is not used, or knowingly present in the manufacturer, or production of their products. www.rshydro.co.uk/files/Solinst-PFAS-Statement.pdf
