Manta F35 Anti-Fouling Multiprobe
- Copper-filled Silicone Nose Cone Covers all of the exposed sensors except the critical measurement surfaces.
- Suitable for Handheld and Unattended Monitoring
- Built-In Datalogger Store >1,000,000 readings
Overview
The Manta F35 Anti-Fouling Multiprobe provides water quality measurement for a wide range of parameters.
Different sizes of multiprobe are available depending on the number of sensors required. The F30 can hold up to 7 sensors whilst the F35 can hold up to 11 sensors.
Available parameters:
- Temperature
- Optical DO
- Conductivity (SC)
- Salinity
- TDS
- Turbidity
- ORP
- pH
- Depth
- Level
- Ammonium
- Nitrate
- Chloride
- TDG
- Chlorophyll a
- Rhodamine
- Blue Green Algae
Manufactured by: Eureka
Model: Manta F35 Anti-Fouling Multiprobe
Services offered for this product
- Sales
- Rental
- Installation
- Calibration
- Maintenance
Applications
Groundwater interaction
Saltwater intrusion
Surface water
Reservoir and lake monitoring
Estuary monitoring
Watershed and source water protection
Beach monitoring
Storm water runoff
NPS monitoring
Vertical profiling
Specification
| Temperature | |
| Range | -5° C - 50° C |
| Accuracy | ±0.1% |
| Resolution | 0.01° C |
| Dissolved 0xygen (% Sat) | |
| Range | 0 - 200% 200 - 500% |
| Accuracy | ±2.4% ±7.2% |
| Resolution | 0.1 |
| Optical DO | |
| Dissolved oxygen (mg/L) | |
| Range | 0 - 25 mg/L |
| Accuracy | 1% of reading or 0.02 mg/L, whichever is greater |
| Resolution | 0.01 mg/L; |
| Dissolved oxygen (% Sat) | |
| Range | 0 - 200 % |
| Accuracy | 1% of reading or 0.02 mg/L, whichever is greater |
| Resolution | 0.1 |
| Conductivity (SC) | |
| Range | 0 - 100 mS/cm |
| Accuracy | 1% reading ± 1 count |
| Resolution | 4 digits |
| Salinity | |
| Range | 0 - 70 PSU (PPT) |
| Accuracy | ±1% of reading or 0.1 PSU, whichever is greater |
| Resolution | 4 digits |
| TDS | |
| Range | 0 - 65 g/L |
| Accuracy | Calculated from Conductivity |
| Resolution | 4 digits |
| Turbidity | |
| Optical 90° Nephelometric Mechanical Wiper | |
| Range | 0 - 3000 NTU |
| Accuracy | 0 - 100 < 1% of reading 100 - 400 < 3% of reading over 400 < 5% of reading |
| Resolution | 0.1 |
| pH | |
| Range | 0 - 14 units |
| Accuracy | ± 0.2 units |
| Resolution | 0.01 units |
| ORP | |
| Range | -999 - 999 mV |
| Accuracy | ± 20 mV |
| Resolution | 1 mV |
| Depth | |
| Range | 10m, 25m, 50m, 100m, 200m |
| Accuracy | ± 0.1% Full scale |
| Resolution | 0.01 m |
| Level | |
| Range | 0 - 10 meters |
| Accuracy | 0.003 meters |
| Resolution | 0.001 |
| Ammonium | |
| Range | 0 - 100 mg/L Nitrogen |
| Accuracy | ± 10% of reading or 2 mg/L whichever is greater |
| Resolution | 0.1 mg/L -N |
| Nitrate | |
| Range | 0 - 100 mg/L Nitrogen |
| Accuracy | ± 10% of reading or 2 mg/L whichever is greater |
| Resolution | 4 digits |
| Chloride | |
| Range | 0.5 - 18,000 mg/L |
| Accuracy | ± 10% of reading or 2 mg/L whichever is greater |
| Resolution | 4 digits |
| TDG | |
| Range | 400 - 1400 mm/Hg |
| Accuracy | ± 0.5 mm/Hg |
| Resolution | 0.1 mm/Hg |
| Chlorophyll a | |
| Range | 0.03 - 50 µg/L |
| Accuracy | ± 3% |
| Resolution | 0.01 µg/L |
| Rhodamine | |
| Range | 0.04 to 1000 ppb |
| Accuracy | ± 3% |
| Resolution | 0.01 ppb |
| Blue green algae | |
| Range | 100 - 200,000 cells/mL |
| Accuracy | ± 3% |
| Resolution | 20 cells/mL |
